ACQC

ACQC

PRODUCT

Automatic Clean
Quick Coupler

ACQC Designed for safe delivery of high purity chemicals from the ISO-Container without pollution.

  • Global No. 1 supply record (Supplied "3481 set" since 1995, Domestic and overseas)
  • Cyclone washing & Drying
  • Chemical Keycode system (Prevention miss connection of male into female coupler)
  • Large flow capacity
  • All hose less type
  • Upholding front square flange
  • O-ring less check plunger

Specification

Size50A (2")
40A (1 1/2")
20A (3/4")
Cv Flow Factor
50A : 31.2
40A : 11.4
20A : 2.7
Wetted Part Material
Acid, Alkali : PTFE, O-Ring → Kalrez
Solvent : SUS 316L EP, O-Ring → Kalrez
Used Pressure
5.0kg/cm²
Pneumatic Pressure
2", 1 1/2" : 4.5 ± 0.1 kgf/cm²
3/4" : 3.0 ± 0.1 kgf/cm²
D.I.W washing
Pressure : 1.5 ~ 2.0 kgf/cm²
Flow Rate : 20 ~ 30 NL/min
N2 Blowing
Pressure : 2.0 ~ 2.5 kgf/cm²
Flow Rate : 350~ 450 NL/min
Operation Temperature Range
ACQC Female : 5℃ ~ 50℃ (Teflon), 5℃ ~ 50℃ (SUS)
ACQC Male : -30℃ ~ 50℃ (Teflon), -30℃ ~ 50℃ (SUS)

PRODUCT

Automatic Clean Quick Coupler

ACQC Designed for safe delivery of high purity chemicals from the ISO-Container without pollution.

  • Global No. 1 supply record (Supplied "3481 set" since 1995, Domestic and overseas)
  • Cyclone washing & Drying
  • Chemical Keycode system (Prevention miss connection of male into female coupler)
  • Large flow capacity
  • All hose less type
  • Upholding front square flange
  • O-ring less check plunger

Integrated CCSS System

Built on ACQC technology, our integrated CCSS system combines ACQC and CCSS to ensure safe, stable, and contamination-free chemical delivery from tank lorry to storage tank to production equipment.

  • Safe & Reliable Secure storage and supply of chemicals essential for LCD panel production
  • Efficient Management Streamlined chemical receiving and delivery to wet process equipment
  • Flexible Operation Supplies the right amount, at the right time, to the right location
  • Centralized Control Real-time monitoring and control for maximum operational safety

[Combo System Flow]

[CCSS System]

PRODUCT

Ordering Information

ACQC Female Coupler

B : Coupler size
C : Chemical Key-code
D : Material
E : Connection Type
F : Flange size
50 : 2" (50A)
Key-code number
T : PCTFE
S : Stainless still
(316L Electric Polishing)
11 : JIS 10K Flange
200 : 2" (50A)
(only one type)
40 : 1 1/2" (40A)
Key-code number
T : PCTFE
S : Stainless still
(316L Electric Polishing)
11 : JIS 10K Flange
200 : 2" (50A)
(only one type)
25 : 1" (25A)
U : UNIVERSAL
(only one type)
T : PCTFE
S : Stainless still
(316L Electric Polishing)
21 : Female Thread(NPT)
(only one type)
100 : 1"
(only one type)
20 : 3/4" (20A)
U : UNIVERSAL
(only one type)
T : PCTFE
S : Stainless still
(316L Electric Polishing)
21 : Female Thread(NPT)
(only one type)
06 : 3/4"
(only one type)

ACQC Female Coupler

B : Coupler size
C : Chemical Key-code
D : Material
E : Connection Type
F : Flange size
50 : 2" (50A)
Key-code number
C : PCTFE
S : Stainless still
(316L Electric Polishing)
11 : JIS 10K Flange
01: ANSI #150 Flange
21N : Female thread (NPT)
21P : Female thread (PT)
200 : 2" (50A)
104 : 1 1/2" (40A)
102 : 1 1/4" (32A)
40 : 1 1/2" (40A)
Key-code number
C : PCTFE
S : Stainless still
(316L Electric Polishing)
11 : JIS 10K Flange
01: ANSI #150 Flange
21N : Female thread (NPT)
21P : Female thread (PT)
200 : 2" (50A)
104 : 1 1/2" (40A)
102 : 1 1/4" (32A)
25 : 1" (25A)
U : UNIVERSAL
(only one type)
C : PCTFE
(only one type)
21 : Female Thread(NPT)
01: ANSI #150 Flange
21N : Female thread (NPT)
21P : Female thread (PT)
102 : 1 1/4" (32A)
100 : 1" (25A)
06 : 3/4" (20A)
20 : 3/4" (20A)
U : UNIVERSAL
(only one type)
C : PCTFE
(only one type)
21 : Female Thread(NPT)
01: ANSI #150 Flange
21N : Female thread (NPT)
21P : Female thread (PT)
100 : 1" (25A)
06 : 3/4" (20A)

Specification

Size50A (2")
40A (1 1/2")
20A (3/4")
Cv Flow Factor
50A : 31.2
40A : 11.4
20A : 2.7
Wetted Part Material
Acid, Alkali : PTFE, O-Ring → Kalrez
Solvent : SUS 316L EP, O-Ring → Kalrez
Used Pressure
5.0kg/cm²
Pneumatic Pressure
2", 1 1/2" : 4.5 ± 0.1 kgf/cm²
3/4" : 3.0 ± 0.1 kgf/cm²
D.I.W washing
Pressure : 1.5 ~ 2.0 kgf/cm²
Flow Rate : 20 ~ 30 NL/min
N2 Blowing
Pressure : 2.0 ~ 2.5 kgf/cm²
Flow Rate : 350~ 450 NL/min
Operation Temperature Range
ACQC Female : 5℃ ~ 50℃ (Teflon), 5℃ ~ 50℃ (SUS)
ACQC Male : -30℃ ~ 50℃ (Teflon), -30℃ ~ 50℃ (SUS)

Gallery

Integrated CCSS System

Built on ACQC technology, our integrated CCSS system combines ACQC and CCSS to ensure safe, stable, and
contamination-free chemical delivery from tank lorry to storage tank to production equipment.

  • Safe & Reliable Secure storage and supply of chemicals essential for LCD panel production
  • Efficient Management Streamlined chemical receiving and delivery to wet process equipment
  • Flexible Operation Supplies the right amount, at the right time, to the right location
  • Centralized Control Real-time monitoring and control for maximum operational safety

[Combo System Flow]

[CCSS System]

Ordering Information

ACQC Female Coupler

B : Coupler size
C : Chemical Key-code
D : Material
E : Connection Type
F : Flange size
50 : 2" (50A)
Key-code number
T : PCTFE
S : Stainless still
(316L Electric Polishing)
11 : JIS 10K Flange
200 : 2" (50A)
(only one type)
40 : 1 1/2" (40A)
Key-code number
T : PCTFE
S : Stainless still
(316L Electric Polishing)
11 : JIS 10K Flange
200 : 2" (50A)
(only one type)
25 : 1" (25A)
U : UNIVERSAL
(only one type)
T : PCTFE
S : Stainless still
(316L Electric Polishing)
21 : Female Thread(NPT)
(only one type)
100 : 1"
(only one type)
20 : 3/4" (20A)
U : UNIVERSAL
(only one type)
T : PCTFE
S : Stainless still
(316L Electric Polishing)
21 : Female Thread(NPT)
(only one type)
06 : 3/4"
(only one type)

ACQC Male Coupler

B : Coupler size
C : Chemical Key-code
D : Material
E : Connection Type
F : Flange size
50 : 2" (50A)
Key-code number
C : PCTFE
S : Stainless still
(316L Electric Polishing)
11 : JIS 10K Flange
01: ANSI #150 Flange
21N : Female thread (NPT)
21P : Female thread (PT)
200 : 2" (50A)
104 : 1 1/2" (40A)
102 : 1 1/4" (32A)
40 : 1 1/2" (40A)
Key-code number
C : PCTFE
S : Stainless still
(316L Electric Polishing)
11 : JIS 10K Flange
01: ANSI #150 Flange
21N : Female thread (NPT)
21P : Female thread (PT)
200 : 2" (50A)
104 : 1 1/2" (40A)
102 : 1 1/4" (32A)
25 : 1" (25A)
U : UNIVERSAL
(only one type)
C : PCTFE
(only one type)
21 : Female Thread(NPT)
01: ANSI #150 Flange
21N : Female thread (NPT)
21P : Female thread (PT)
102 : 1 1/4" (32A)
100 : 1" (25A)
06 : 3/4" (20A)
20 : 3/4" (20A)
U : UNIVERSAL
(only one type)
C : PCTFE
(only one type)
21 : Female Thread(NPT)
01: ANSI #150 Flange
21N : Female thread (NPT)
21P : Female thread (PT)
100 : 1" (25A)
06 : 3/4" (20A)

Gallery
